7 inch LCD color monitor Wireless Reversing Camera , Automobile Wireless Backup Camera

Name: 7 inch LCD color monitor Wireless Reversing Camera , Automobile Wireless Backup Camera
Brand: SEEPOWER
SKU: CR006
Rating: 4.7 (176 reviews)

Large Image : 7 inch LCD color monitor Wireless Reversing Camera , Automobile Wireless Backup Camera

Product Details:

Place of Origin:	China
Brand Name:	SEEPOWER
Certification:	CE/ROHS/FCC
Model Number:	CR006

Payment & Shipping Terms:

Minimum Order Quantity:	10 - 50 sets
Price:	negotiation
Packaging Details:	1 set packed in inner gift box,10 sets in standard export carton.
Delivery Time:	25 - 30 working days for 10,000pcs
Payment Terms:	T/T or western Union,Paypal
Supply Ability:	10,000pcs per month

Contact Now

Detailed Product Description

Receiver:

Monitor

Viewing Angle:

110 Degree

Definition:

H:480 V:234

Lens:

Highlight:

Cordless Backup Camera

Wireless Reverse Parking Camera

SEEPOWER wireless car backup camera with 7.0 - inch LCD color monitor

Specifications:

Main specifications of the system
Monitor	P / N	SEEPOER CR006
	Monitor size	7” color LCD
	Power	12 - 24 VDC
	Definition	480 x 234 pixels
	Receiving sensitivity	≤ 85dBm
	TV system	PAL / NTSC
Camera ( TX )	Type of Lens	OV
	Sensor	1 / 3 inch CMOS
	Frequency	2.4GHz
	Resolution	130M
	Infra-red LEDs	15 pcs
	Viewing angle	110°
	Night vision	5m
	Transmitter	Integrated
	Transmission range	100 - 300m ( obstructed / unobstructed )
	Operation temperature	- 10 ℃ - 60 ℃

Description:

SEEPOWER wireless car backup camera with 7.0 - inch LCD color monitor

15pcs of IR leds bring up to 5 meters distance vision in the night.ideal for SUV, MPV, trailer, truck, bus, Lorry and so on. with clear real - time video to make sure your secure when reversing.it's becoming a easy matter from now on.
* real - time display for reversing

* colorful lines compose 4 blocks of ladder - shaped grids,as guide line to help judge distance.
* No extra cable for long vehicles,minimum 100 meters transmission range.

* Rated power supply is 12V and 24V.

* Wide viewing angle up to 110 degrees

* 100% to assure waterproof for the camera

* At least 5 meters far for night vision

* Quick setup and easy operation

* Adjustable U - shaped bracket

* Larger monitor 7 inches, Support A / V input,loud speaker about 80dBA.

* Extra suction cup included

Easy Installation :
* Put the camera on proper position,fix it with screws.
* Connect power cable red +, black - to power system correctly.
* Use the car kit to power the monitor.

Accessories :
1 x Monitor
1 x Camera
1 x Suction cup
1 x Car charger(for monitor)
1 x User manual

Applications:

all vehicles, cars, trucks, trailers and so on.

Toubleshooting:

Problem	Situation	Solution
Monitor without any response, (black screen or unclear)	The lens of the camera may be covered with dust, snow, mud, ice, etc.	Clean the lens.
	The camera is mounted incorrectly or has been moved away	Check camera’s position and alignment. Realign it as necessary.
	No power to the monitor or camera	Ensure power on and connect the wires correctly to the monitor, transmitter, camera and into the vehicle reverse light circuit. Check all wire connections and splices for proper connection
	Monitor powered off	Check the car charge if there is power output
	Camera is angled incorrectly	Adjust camera angle
	Screen settings are incorrect	Adjust camera angle
	Monitor is angled incorrectly	Adjust monitor angle using adjustment knobs.
