Wireless
|
|
Compatible Mobile Networks
|
3G UMTS WCDMA (HSDPA);
2G GSM EDGE/GPRS
|
|
Cellular Frequency
|
UMTS/HSDPA (WCDMA/FDD): 850/1900/2100 MHz, option for 850/900/1900/2100Mhz/1700Mhz/AWS;
Quad-band GSM/GPRS/EDGE 850/900/1800/1900Mhz;
|
|
Bandwidth
|
HSDPA: Downlink 7.2 Mbps, Uplink 384k bps;
WCDMA/UMTS: Downlink/Uplink 384 kbps;
EDGE: Downlink 384 kbps, Uplink 118 kbps;
GPRS: Downlink 108 kbps, Uplink 42.8 kbps;
Notes: the bandwidth is peak value. Real value depends on carrier network support.
|
|
Network and Band Lock Feature (Option)
|
Default is unlocked, can use this feature to lock
|
|
Main Features and Performance
|
|
USB Host
|
No, can ODM
|
|
SMS/Voice
|
SMS/Voice call to control router to be online, offline, reboot and status monitor; SMS is default feature, Voice is option
|
|
GPS (Option)
|
GPS feature
|
|
DTU (Option)
|
With DTU feature (Serial to Cellular Gateway feature, RS232 or RS485 port option).
Details:
Serial Baudrate: 300bps, 600bps, 1200bps, 2400bps, 4800bps, 9600bps, 19200bps, 38400bps, 57600bps, 115200bps;
Serial Parity: none, even, odd;
Serial Databits: 7, 8;
Serial stopbits: 1, 2;
Serial flow control: none, hardware, software;
Mode: Server (up to 4 server centre, can OEM to be more), Client;
Protocol: TCP, UDP ;
Heart Beat : Yes;
|
|
VPN
|
PPTP, L2TP, IPSec, GRE, Tunnel (PPTP server, PPTP client, L2TP client, IPSec client, IPsec server)
|
|
OpenWRT (Option)
|
Optional
|
|
VRRP (Option)
|
Optional
|
|
Route
|
Static Route;
Optional for Dynamic Route (BGP, BGPD, OSPF, Zebra, Rip);
|
|
SNMP
|
Support V1, V2. V3
|
|
VLAN
|
Support multi-LAN IP address, support two IP address
|
|
Wi-Fi
|
Optional, 802.11b/g/n; 150Mbps default. 300Mbps optional.
Can be used as AP and client;
Frequency from 2.4GHz to 2.483GHz,Access Points, Routers and Gateway Server Applications, wireless up to 254 PC users
|
|
Fail Over Redundancy (network Backup feature)
|
Auto-dial feature, keep alive link;
LCP, ICMP check;
Built-in watch dog;
Dual cellular (2G/3G/4G), RJ45 WAN (xDSL, DHCP, Fixed IP), WiFi client four line redundancy;
Cold Backup is default, Hot Backup is option;
Cold Backup=WAN RJ45 and Cellular WAN not online at the same time. One line online and the other line standby, switch freely with triggers;
Hot Backup=WAN RJ45 and Cellular WAN are online at the same time. Data goes the main line, and switch to the other line. Hot Backup switch time is shorter than Cold Backup.
|
|
POE
|
POE for LAN/WAN RJ45 (use with POE adapter)
|
|
Firmware update
|
support firmware update locally or remotely (LAN, WiFi and OTA WAN)
|
|
Syslog
|
local and remote
|
|
DDNS
|
Yes
|
|
DHCP Server
|
Yes
|
|
Internal Battery
|
Optional (8000mAH, 4000mAH *2)
|
|
Others
|
DNS proxy;
Optimized EMC design;
Real-time clock (NTP, support update with defined hours);
WAN/LAN/Memory statistics;
Local/remote profiles backup and retrieve;
|
|
Management System
|
Option
|
|
Protocol
|
|
|
Protocol support
|
TCP, UDP, SMTP, POP, ICMP, FTP, PPP, PPPoE, DHCP, DDNS, DNS, WPS, DMZ, NAT, xDSL, NTP, QoS, etc.
|
|
Security
|
|
|
Firewall
|
support 64/128 bits WEP, 802.1x, WPA, and WPA2
support WDS
support WPA1/2 – PSK
support WPA1/2 – 802.1x
support EAP – TLS, TTLS, LEAP, PEAP
TKIP, AES encryption
support access with user name & password.
support access control base WAN/LAN interface
support access control base source IP address
defense DOS attack, support SYN flooding, IP surfing, ping of Death, fragile, teardrop, land etc.
support PAP & CHAP
support IP filtering
support content filtering
support NAT/NAPT/Port forwarding/DMZ
|
|
Advanced Firewall Features
|
Stateful Packet Inspection (SPI)
VPN Pass-through
|
|
Media Access Control
|
CSMA/CA with ACK
|
|
Certifications
|
REDIUS Client
|
|
Interface
|
|
|
LAN/WAN
|
4X 10/100M LAN port (RJ45 interface)
1X 10/100M WAN port (RJ45 interface)
(WAN RJ45 can convert into LAN RJ45 to get 2 LAN RJ45);
WAN ports support Cell/Static IP/DHCP/PPPoE (on demand, keep alive, schedule, manual)
|
|
Antenna
|
1-5 antenna (50Ω SMA female interface, detachable):
Wi-Fi*2
Cellular*1 or 2
GPS*1
Cellular support MIMO(Diversity Receiving) option;
WiFi support MIMO (Diversity Receiving) option;
|
|
Led
|
SYS
VPN
WiFi
Cell1
Cell2
Cell Signal1
Cell Signal2
LAN (10/100M) 1, 2, 3, 4
WAN
CHR (Internal battery charging)
|
|
Button
|
Reset
|
|
Console
|
1 console port (also can be used as M2M port)
|
|
Serial port
|
|
RS232 or RS485 with DB9 and Terminal Block interface
|
|
|
IO Port (option)
|
2
|
|
Management
|
Easy to use and management;
Web/Telnet/SSH/CLI, support remote management
SMS;
SNMP;
RMS (Remote Management System)
|
|
At command
|
Supported
|
|
UIM/SIM Card Slot
|
Support 1.8V/3V UIM/SIM cards, one sim card slot
|
|
DC Jack
|
Two types of input jack for DC
2.5mm DC jack * 1
Terminal Block * 1
|
|
Power
|
|
|
Power supply
|
DC5V-50V , typical DC 9V1A or 12V1A, 12v CAR USE;
DC5V~40V is the default, DC5V~50V is the option
|
|
Current
|
Idle: about 140mA@12VDC
Communication: about 300mA@12VDC
|
|
Software
|
|
|
Device Management
|
WEB interface (Internet Explorer v6 or Later; Mozilla Firefox v1.5 or Later, or other Java-enabled Browsers, Chome, Opera, Sarafi, etc.)
|
|
Minimum System Requirements
|
Windows, Linux, Mac OS, IOS, Symbian, Android, other OS support web browser;
Network Interface Card
|
|
Physical
|
|
|
Operating Temperature
|
Storage Temperature: -40 ~ 85°C
Working Temperature: -30 ~ 75°C
|
|
Humidity
|
95% Maximum (Non-condensing)
|
|
Dimensions
|
PCBA: 168mm x 111mm x 16mm
With case: 180mm x 114mm x 32mm
|
|
Weight
|
705g (not including the antenna)
|
|
Color
|
Metal Gray-Black, OEM is available
|
|
Others
|
|
|
Warranty
|
1 Year default. Option extends to 5 years maximum.
|
